3030 Small Fiber 1000w Laser Cutting Machine With High Precision

3030 Small Fiber 1000w Laser Cutting Machine With High Precision

Small fiber laser cutting machine with high precision laser power 1000-6000w

Features and advantages

★Adopting advanced gantry structure, the workpiece does not move during processing and the laser head moves the plane laser cutting machine.

★Precision transmission parts are not in the cutting area, so the protection is easy, and the precision of the machine tool will not be affected by the thermal deformation of the workbench and bed.

★Using the double-sided drive of the motor avoids the twisting of the beam, which makes the optical path of the machine run stable and the cutting precision improved.

★Using imported precision screw drive, the maximum positioning speed is fast and the processing efficiency is high.

★A centralized lubricating device is adopted to automatically lubricate the transmission parts through system control, thus ensuring the precision and service life of the transmission parts.

★Adopt high-precision laser cutting head, it is more convenient to replace the focusing lens.

★High-end programming nesting software with unique functions in punching holes and sharp corner processing.

★Automatic follow-up to achieve consistent spot size and constant focus within the entire processing range of the optical path, ensuring cutting quality.

^{1. Configuration}

^{2. Parameter}

^{3. Working condition}

^{4. Machine proposal}

^{4. 1 The Machine rack adopts marble structure and US CNC laser cutting system. With Integrated designing, through gantry milling machine processing ,so to make the movement be accurate .linear motor driving system, friendly interface and long term stable working.}

^{Adopted THK Japan precision linear guide rail, with high accuracy, low abrasion and easy to be assembled or exchanged.}

^{4. 2 laser cutting head}

^{BT230 (Raytools, Switzerland brand ) laser cutting head with auto focus system. It can prevent materials waste from distortion cutting. The protection glass can keep and protect the low cost of the important optical parts inside of the cutting head. Auto focus system is suitable for non-flat metal sheet processing. Combined with high quality lasers the BT230 can be widely used in ceramic, medical, semiconductor and other industries.}

^{4. 3 Control system:}

^{The use of professional PC industrial computer operation, graphical interface, easy to operate, professional cutting control software can freely design a variety of graphics and text, real-time processing, support CAD, CorelDraw and other professional mapping software.}

^{. High-quality industrial computer control operation}

^{. High efficient, easy to operate CNC cutting system}

^{.  Z axis automatic tracking function}

5.CNC cutting control system

^{CNC cutting control system is the use of high-performance control card, based on Windows XP Professional development, fully docking with CNC control system, therefore, the real-time control and software upgrates between machine and laser source more convenient and fast.}

^{Main features of control system:}

• ^{Stable operation,good anti-interference ability}
• ^{Fast moving speed, smooth start and stop}
• ^{Good cutting effect, fast cutting speed}
• ^{Enhanced capacity for large data processing}
• ^{Output control:support unified entity output mode, support any position to start cutting, combined with the NC and graphics two output modes, can be modified after the stop parameters.}

^{Cutting samples:}
